OUTSIDE BACK EXHAUST
(Horizontal Duct)
INSTALLATION OVERVIEW
B1. Prepare Rear Wall
B2. Remove Exhaust Adaptor
B3. Attach Mounting Plate to Wall
B4. Prepare Top Cabinet
B5. Adapt Blower for Back Exhaust
B6. Mount the Microwave Oven
Installation Instructions
B
15
PREPARING THE REAR WALL
FOR OUTSIDE BACK EXHAUST
B1.
The rear wall template should be positioned accurately
as shown on page 9.
• Read the instructions on the REAR WALL
TEMPLATE.
• Cut the opening, following the instructions of the
REAR WALL TEMPLATE.
