GE 489 Communications Guide

54 489 GENERATOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
F212
Unsigned
16 bit integer
RTD NUMBER
0All
1RTD #1
2RTD #2
3RTD #3
4RTD #4
5RTD #5
6RTD #6
7RTD #7
8RTD #8
9RTD #9
10 RTD #10
11 RTD #11
12 RTD #12
F213
Unsigned
16 bit integer
COMMUNICATIONS MONITOR PORT SELECTION
0 Computer RS485
1Auxiliary RS485
2 Front Panel RS232
F214
Unsigned
16 bit integer
WAVEFORM MEMORY CHANNEL SELECTOR
0
Phase A Line Current
512 counts = 1 × CT
1
Phase B Line Current
512 counts = 1 × CT
2
Phase C Line Current
512 counts = 1 × CT
3
Phase A Line Current
512 counts = 1 × CT
4
Neutral-End Phase A Line Current
512 counts = 1 × CT
5
Neutral-End Phase B Line Current
512 counts = 1 × CT
6
Neutral-End Phase C Line Current
512 counts = 1 × CT
7
Phase A to Neutral Voltage; 3500 counts = 120
secondary volts
8
Phase B to Neutral Voltage; 3500 counts = 120
secondary volts
9
Phase C to Neutral Voltage; 3500 counts = 120
secondary volts
F215
Unsigned
16 bit integer
CURRENT SOURCE
0Neutral-End CTs
1 Output-End CTs
F216
Unsigned
16 bit integer
DNP PORT SELECTION
0None
1 Computer RS485
2Auxiliary RS485
3 Front Panel RS485
F217
Unsigned
16 bit integer
GROUND DIRECTIONAL MTA
0 0 degrees
1 90 degrees
2 180 degrees
3 270 degrees
Table CG–2: Data Formats (Sheet 13 of 14)
CODE TYPE DEFINITION
