49-5000574 Rev. 1 13
Installation Instructions
INSTALLATION INSTRUCTIONS
6. INSTALL WINDOW LOCK
BRACKET AND FOAM TOP
WINDOW GASKET
8VH7\SH%6FUHZWRLQVWDOOWKHZLQGRZORFN
bracket on top of the bottom window.
A.
CAUTION
To prevent broken glass or
damage to windows, on vinyl
or other similarly constructed
windows, attach the window
locking bracket to the
ZLQGRZVLGHMDPEZLWKRQH
Type B screw.
B. Cut the foam top window gasket to the window
width.
C. Stuff the foam between the glass and the
window to prevent air and insects from getting
into the room.
NOTE: If the gasket supplied does not fit your
window, obtain appropriate material locally to
provide a proper installation seal.
Wood
Vinyl
