GEI
-
86150
-
A
Figure
9
,
AKRU
-
5
A
-
30
integrally
fused
breaker
REJECTION
BRACKET
SNTERCHAWGE
ABILITY
OF
DRAWOUT
BREAKERS
In
general
,
drawout
breakers
of
the
same
type
and
rating
are
interchangeable
in
their
equipment
compartments
;
drawout
breakers
of
different
frame
sizes
or
short
circuit
ratings
are
intentionally
made
non
-
interchangeable
.
To
prevent
inserting
the
wrong
type
breaker
into
a
drawout
compartment
,
unique
rejection
hardware
is
affixed
to
each
breaker
and
its
compart
-
ment
.
Figure
9
shows
a
typical
breaker
-
mounted
rejection
bracket
which
aligns
with
a
rejection
pin
in
the
drawout
rail
(
Fig
.
10
)
.
When
the
wrong
type
breaker
is
inserted
into
a
compart
-
ment
,
the
bracket
and
pin
do
not
mate
,
preventing
the
breaker
from
seating
itself
into
the
rail
slots
.
There
is
one
exception
to
the
above
.
Breakers
of
the
same
frame
size
having
different
short
circuit
ratings
may
be
interchanged
in
one
direction
only
.
Specifically
,
a
.
An
AKR
-
30
H
can
be
inserted
into
an
AKR
-
30
compartment
.
b
.
An
AKR
-
50
H
can
be
inserted
into
an
AKR
-
50
compartment
.
The
rejection
hardware
prevents
the
converse
of
a
.
and
b
.
Figures
15
,
16
and
17
display
the
rejection
pin
/
bracket
combinations
employed
for
the
various
breaker
models
and
frame
sizes
.
As
dictated
by
its
intended
breaker
type
,
each
drawout
compartment
has
its
rejection
pin
(
s
)
installed
in
posi
-
tions
A
,
B
or
C
(
Fig
.
10
and
14
)
along
the
drawout
rails
.
The
AKRU
-
30
and
-
50
fused
breakers
employ
a
single
bracket
,
while
all
non
-
fused
breakers
carry
two
brackets
.
Note
that
the
rejection
hardware
is
identical
for
both
A
and
B
-
type
breakers
:
however
,
because
their
escutcheons
are
differ
-
ent
,
the
breakers
are
not
interchangeable
.
D
type
breaker
rejection
hardware
is
different
than
A
or
B
type
(
Fig
.
12
and
13
)
FRONT
OF
COMPARTMENT
FRONT
SLOT
PIN
IN
POSITION
"
A
"
RAIL
/
in
)
C
B
A
\
SH
©
I
1.12
PIN
RIGHT
SIDE
Fig
.
10
Slide
rail
rejection
pin
locations
(
A
-
type
rail
shown
)
14
Courtesy of NationalSwitchgear.com
