Maintenance
2001989-351A ApexPro™ 4-3
Antenna infrastructure tests
Subsystem tests
Transmitter tests
Test
Quick Antenna System Checks. See Quick antenna system checks on page 5-7.
ApexPro CH Antenna System Test Instructions:
Antenna System installation verification tests
Out-of-Band RF Signal Test
Unity Signal Gain Test with Transmitter
Noise Floor Performance Test
In-band Noise Test
Test
Visual inspection - General. See Visual inspection on page 4-4.
Cleaning. See Cleaning on page 4-5.
Receiver calibration (Systems that include T14 transmitters only. Only need to
perform every two years). See Receiver calibration on page 4-15.
Receiver System Checkout. See Receiver system checkout on page 7-3.
LED Status Indicators
Verify Connectivity
Receiver Function
Electrical Safety Tests. See Electrical safety tests on page 7-7.
Test
Transmitter calibration (T14 transmitters only. Only need to perform every two years).
See Transmitter calibration on page 4-10.
