49-5000527 Rev. 3 13
Installation Instructions
INSTALLATION INSTRUCTIONS
5. Connect Exhaust Hose to the Air Conditioner
NOTE: When connecting the hose, the air conditioner must be close enough to the window that you will not
dislodge the window seal plate. Once the hose is connected, move the air conditioner 20” (51 cm) from the wall.
1. Extend the flexible exhaust hose to reach out to the unit.
2. Aim the opening of the hose to the air exhaust outlet and push it hard straight into the outlet until it clicks.
1 2
3 4
