11
Installation Instructions
NOTE: If installing slider in a double hung
window, go back to step 4 on page 9 and
proceed.
INSTALL WINDOW SLIDER
IN A SLIDING WINDOW
OR PATIO DOOR
If the window slider is shorter than the
height of the window, pull the sliding arm
out to the height of the window.
If the window slider is longer than the
height of the window, cut the slider arm
to the height of the window.
If the two-piece window slider is too short
for the height of the window, attach and
use the third piece of the slider.
Cut the window seal (adhesive-backed) to
the window height and stick the adhesive
side to the inner window sliding face, as
shown above.
Attach the top of the slider to the window
face using a screw through one of its holes.
Slide the window against the edge of the
window slider.
4
A
B
C
D
Inside
Wood screw
Inside
Third piece of slider
for extra long windows
