GE Autotrol Performa ProSoft 960 Series - Page 24

24
Brine
Adjustment
Brine Tank
Mineral Tank
Drain
Inlet
Outlet
Hard Water
Soft Water
5
4
1
3
2
6
7
Brine
Adjustment
Brine Tank
Mineral Tank
Drain
Inlet
Outlet
Hard Water
Soft Water
5
4
1
3
2
6
7
Mineral Tank
Brine
Adjustment
Brine Tank
Mineral Tank
Drain
Inlet
Outlet
Hard Water
Soft Water
5
4
1
3
2
6
7
3 Brining/Slow Rinse Position
4 Purge Position
Valve
No.
1 - Open
2 - Open
3 - Closed
4 - Closed
5 - Closed
6 - Open
7 - Closed
Valve
No.
1 - Closed
2 - Open
3 - Open
4 - Closed
5 - Closed
6 - Open
7 - Closed
Valve
No.
1 - Closed
2 - Closed
3 - Open
4 - Open
5 - Open
6 - Closed
7 - Closed
5 Regenerant Refill Position
