GE Autotrol Performa ProSoft 960 Series - Identification of Control Valving; Valve Disc Principle of Operation; Flow Diagrams

23
Identification of Control Valving
Brine
Adjustment
Brine Tan
k
Mineral Tank
Drain
Inlet
Outlet
Hard Water
Soft Water
5
4
1
3
2
6
7
Brine
Adjustment
Brine Tan
k
Mineral Tank
Drain
Inlet
Outlet
Hard Water
Soft Water
5
4
1
3
2
6
7
Backwash
Flow
Control
2 Backwash Position
1 Regenerant Valve
2 Bypass Valve
3 Inlet Valve
4 Outlet Valve
5 Refill Valve
6 Rinse Drain Valve
7 Backwash Drain Valves
Flow Diagrams
Valve
No.
1 - Closed
2 - Closed
3 - Open
4 - Open
5 - Closed
6 - Closed
7 - Closed
Valve
No.
1 - Closed
2 - Open
3 - Closed
4 - Open
5 - Closed
6 - Closed
7 - Open
1 Service Position
Valve Disc Principle of Operation
