2-100 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 6B20 ...Repeated for Undervoltage 5
" 6B2C ...Repeated for Undervoltage 6
" 6B38 ...Repeated for Undervoltage 7
" 6B44 ...Repeated for Undervoltage 8
" 6B50 ...Repeated for Undervoltage 9
" 6B5C ...Repeated for Undervoltage 10
" 6B68 ...Repeated for Undervoltage 11
" 6B74 ...Repeated for Undervoltage 12
End of Fault Protection / End Fault Protection (Read/Write Grouped Setting) (24 Modules)
B90 6B80 End of Fault Protection 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 6B81 End of Fault Protection 1 CT 0 to 23 --- 1 F400 0
" 6B82 End of Fault Protection 1 Pickup 0.02 to 30 pu 0.001 F001 1200
" 6B83 End of Fault Protection 1 Breaker Open 0 to 4294967295 --- 1 F300 0
" 6B85 End of Fault Protection 1 Breaker Delay 0 to 65.535 s 0.001 F001 400
" 6B86 End of Fault Protection 1 Manual Close 0 to 4294967295 --- 1 F300 0
" 6B88 End of Fault Protection 1 Pickup Delay 0 to 65.535 s 0.001 F001 40
" 6B89 End of Fault Protection 1 Block 0 to 4294967295 --- 1 F300 0
" 6B8B End of Fault Protection 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 6B8C End of Fault Protection 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 6B8D ...Repeated for End of Fault Protection 2
" 6B9A ...Repeated for End of Fault Protection 3
" 6BA7 ...Repeated for End of Fault Protection 4
" 6BB4 ...Repeated for End of Fault Protection 5
" 6BC1 ...Repeated for End of Fault Protection 6
" 6BCE ...Repeated for End of Fault Protection 7
" 6BDB ...Repeated for End of Fault Protection 8
" 6BE8 ...Repeated for End of Fault Protection 9
" 6BF5 ...Repeated for End of Fault Protection 10
" 6C02 ...Repeated for End of Fault Protection 11
" 6C0F ...Repeated for End of Fault Protection 12
" 6C1C ...Repeated for End of Fault Protection 13
" 6C29 ...Repeated for End of Fault Protection 14
" 6C36 ...Repeated for End of Fault Protection 15
" 6C43 ...Repeated for End of Fault Protection 16
" 6C50 ...Repeated for End of Fault Protection 17
" 6C5D ...Repeated for End of Fault Protection 18
" 6C6A ...Repeated for End of Fault Protection 19
" 6C77 ...Repeated for End of Fault Protection 20
" 6C84 ...Repeated for End of Fault Protection 21
" 6C91 ...Repeated for End of Fault Protection 22
" 6C9E ...Repeated for End of Fault Protection 23
" 6CAB ...Repeated for End of Fault Protection 24
Bus Replica Isolator (Read/Write Setting) (48 Modules)
B90 6CBC Isolator 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 6CBD Isolator 1 Open 0 to 4294967295 --- 1 F300 0
" 6CBF Isolator 1 Closed 0 to 4294967295 --- 1 F300 0
" 6CC1 Isolator 1 Alarm Delay 0 to 120 s 0.05 F001 5
