CHAPTER 3: IEC 61850 COMMUNICATION ACSI CONFORMANCE STATEMENT
UR FAMILY – COMMUNICATIONS GUIDE 3-27
3
3.4.3 ACSI services conformance statement
The table contains the conformance statement.
Table 3-6: ACSI services conformance statement
M19 GOOSE Control Block Yes
M20 Sampled Value Control Block
Client / subscriber Server / publisher Comments
Server (IEC 61850-7-2 clause 7)
S1 ServerDirectory Yes
Application association (IEC 61850-7-2 clause 8)
S2 Associate Yes
S3 Abort Yes
S4 Release Yes
Logical device (IEC 61850-7-2 clause 9)
S5 LogicalDeviceDirectory Yes
Logical node (IEC 61850-7-2 clause 10)
S6 GetLogicalNodeDirectory Yes
S7 GetAllDataValues Yes
Data object (IEC 61850-7-2 clause 11)
S8 GetDataValues Yes
S9 SetDataValues Yes
S10 GetDataDirectory Yes
S11 GetDataDefinition Yes
Data set (IEC 61850-7-2 clause 13)
S12 GetDataSetValues Yes
S13 SetDataSetValues
S14 CreateDataSet
S15 DeleteDataSet
S16 GetDataSetDirectory Yes
Substitution
S17 SetDataValues
Setting group control (IEC 61850-7-2 clause 16)
S18 SelectActiveSG Yes
S19 SelectEditSG Yes
S20 SetEditSGValue
S21 ConfirmEditSGValues
S22 GetEditSGValue Yes
S23 GetSGCBValues Yes
Reporting (IEC 61850-7-2 clause 17)
Buffered report control block (BRCB)
S24 Report Yes
S24-1 data-change (dchg) Yes
S24-2 qchg-change (qchg) Yes
S24-3 data-update (dupd)
S25 GetBRCBValues Yes
