CHAPTER 3: IEC 61850 COMMUNICATION MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-209
3
3.5.7 GE namespace
The GE namespace is an extension of the "IEC 61850-7-4:2007A" namespace, and as such includes by reference all data
object names in IEC 61850-7-4 Edition 2.0 2010-03. As these names are defined in the standard, they are not described in
this document. The GE namespace schema file "GEExtensionsV1_0.xsd" is located in the same folder as the UR EnerVista
software installation, for example in C:\Program Files (x86)\GE Power Management\URPC\GESchema\
The name of the GE namespace specified for firmware 7.4x in this document is "GE Multilin UR Namespace:2015A"
In the last column, the logical node number is not included. For example, LPHD refers to LPHD1.
Table 3-223: GE namespace
InRef57 ORG Instantiated only if the order code
includes graphical front panel
R
setSrcRef ObjectReference SP LED 5 OPERAND setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef58 ORG Instantiated only if the order code
includes graphical front panel
R
setSrcRef ObjectReference SP LED 6 OPERAND setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef59 ORG Instantiated only if the order code
includes graphical front panel
R
setSrcRef ObjectReference SP LED 7 OPERAND setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef60 ORG Instantiated only if the order code
includes graphical front panel
R
setSrcRef ObjectReference SP LED 8 OPERAND setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef61 ORG Instantiated only if the order code
includes graphical front panel
R
setSrcRef ObjectReference SP LED 9 OPERAND setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
Data object
name
CDC Semantics Used in logical nodes…
AaDmd MV Phase A demand.
SRC 1 DMD IA, in primary amperes.
DmdMtrMMTR
AaMaxDmdDt MV Phase A Max Demand with Date (time stamp). The ClcMth cannot be used for
MAX, as the time stamp definition of IEC 61850 is different from UR.
SRC 1 DMD IA MAX, in primary amperes with associated date, SRC 1 DMD IA DATE.
DmdMtrMMTR
AaRMS MV Phase A current RMS.
SRC 1 Phase A Current RMS, in primary amperes.
ACsrcMMXU
AbDmd MV Phase B demand.
SRC 1 DMD IB, in primary amperes.
DmdMtrMMTR
AbMaxDmdDt MV Phase B Max Demand with Date (time stamp). The ClcMth cannot be used for
MAX, as the time stamp definition of IEC 61850 is different from UR.
SRC 1 DMD IB MAX, in primary amperes with associated date, SRC 1 DMD IB DATE.
DmdMtrMMTR
AbRMS MV Phase B current RMS.
SRC 1 Phase B Current RMS, in primary amperes.
ACsrcMMXU
AcDmd MV Phase C demand.
SRC 1 DMD IC, in primary amperes.
DmdMtrMMTR
AcMaxDmdDt MV Phase C Max Demand with Date (time stamp). The ClcMth cannot be used for
MAX, as the time stamp definition of IEC 61850 is different from UR.
SRC 1 DMD IC MAX, in primary amperes with associated date, SRC 1 DMD IC DATE.
DmdMtrMMTR
AcRMS MV Phase C current RMS.
SRC 1 Phase C Current RMS, in primary amperes.
ACsrcMMXU
LNName: LEDsIHMI1 LDevice inst: Gen UR element: Front Panel LEDs
data obj. data attribute Type FC UR Name Description R/W/C
