3-210 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
Activated SPS Activated. In this logical node, indicates position of a pushbutton. When "true", the
pushbutton is asserted state; when "false", the pushbutton is in a released state.
CONTROL PUSH BUTTON 1 ON operand.
PUSHBUTTON 1 ON operand.
CtlPshIHMI, UsrPbIHMI
Adif CMV Differential current (sum of the three phase currents and the ground (fourth)
current. Restricted ground differential if the fourth current measures the ground
current in a grounded wye winding. Measures CT secondary circuit trouble if
fourth current measures the CT secondary neutral current.
SRC 1 Differential Ground Current phasor, in primary volts.
ACsrcMMXU
Agnd CMV Ground current (fourth input in a current AC bank).
SRC 1 Ground Current phasor, in primary amperes.
ACsrcMMXN
AgndRMS MV Ground current RMS (fourth input in a current AC bank).
SRC 1 Ground Current RMS, in primary amperes.
ACsrcMMXN
AlgCap SPC Command for the Hi-Z Oscillography Force Algorithm Capture HiZPHIZ
AlmInd SPS An LED.
The LED ALARM operand.
LEDsIHMI
AmpInd SPS An LED.
The LED CURRENT operand.
LEDsIHMI
AnFailBeh ENG Setting to select the behavior of the RxGOOSE Analog when the sending device is
offline: 0 = Default Value, 1 = Last Known
GGIO3
AnFailVal ASG The value of the RxGOOSE Analog when the sending device is offline and the
FailBeh is set to "Default Value"
GGIO3
AnOutput1 MV Analog output Cmp8BtGAPC
AnyPBOn SPS Indicates ANY PB ON operand state. When any of the user pushbuttons is
asserted, status is "true"; when none of the user pushbuttons are asserted, status
is "false."
UsrPbIHMI
AnyErr SPS Any of the self-test errors generated. The ANY SELF TESTS operand. LPHD
AnyGpsFail SPS The GPS signal failed or is not configured properly at any terminal.
The 87L DIFF GPS FAIL operand, which becomes On when the GPS signal failed or
is not configured properly at any terminal.
LinDfPDIF
AnyPoleOpn SPS At least one pole is open. The BREAKER 1 ANY P OPEN operand. Bkr0XCBR
AnyShotCnt SPS The first breaker close signal has been issued.
The AR SHOT CNT greater than zero operand.
Rec13pRREC
APPID ING Expected value of APPID field in messages subscribed to by RxGOOSE#
The RxGOOSE1 ETYPE APPID setting.
LGOS
ArBlk1 SPS Autoreclose Breaker number indicated by the data instance number is
temporarily disabled.
The AR BKR1 BLK operand and the AR1 BLK FROM MAN CLS operand.
Rec13pRREC, Rec3pRREC
ArcConfid1 INS Represents the Arc Confidence in percentage for Phase A, B, C, or N HiZPHIZ
ArcSuspect ACT Indicates suspected element has operated HiZPHIZ
AresRMS MV Residual Current RMS.
SRC 1 Neutral Current RMS, in primary amperes.
ACsrcMMXU
ArLO SPS Autoreclose is locked out. The AR LO operand. Rec13pRREC, Rec3pRREC
Armed SPS Accidental energization. Occurs when the generator is offline with no fault
involved. The ACCDNT ENRG ARMED operand.
AcdEnrPIOC
ArMod1 SPS Autoreclosec mode equals to the number indicated by the data instance number,
in this case 1 and 3 pole mode. The AR MODE = 1 operand.
Rec13pRREC
ArRip SPS Autoreclose is in progress. The AR RIP operand. Rec13pRREC, Rec3pRREC
ASupn1 SPS Indicates the state of current supervision.
The PHS DIST Z1 SUPN AB/BC/CA operand in Phase-To-Phase.
PhsDisPDIS
Asymmetry SPS Communications channel asymmetry detected.
The 87L DIFF CH ASYM DET operand, which becomes On when the differential
element's has detected substantial communications channel asymmetry.
LinDfPDIF
AutoMod SPS Capacitor control in auto mode. The CAP 1 IN AUTO operand. CapCtlGAPC
Data object
name
CDC Semantics Used in logical nodes…
