GE b30 Communications Guide

2-106 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
Breaker Failure (Read/Write Grouped Setting) (24 Modules)
B90 7100 Breaker Failure 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 7101 Breaker Failure 1 Initiate 0 to 4294967295 --- 1 F300 0
" 7103 Breaker Failure 1 Use Amp Supervision 0 to 1 --- 1 F126 1 (Yes)
" 7104 Breaker Failure 1 Use Seal In 0 to 1 --- 1 F126 1 (Yes)
" 7105 Breaker Failure 1 Amp Supervision OpA 0 to 4294967295 --- 1 F300 0
" 7107 Breaker Failure 1 Amp Supervision OpB 0 to 4294967295 --- 1 F300 0
" 7109 Breaker Failure 1 Amp Supervision OpC 0 to 4294967295 --- 1 F300 0
" 710B Breaker Failure 1 Use Timer1 0 to 1 --- 1 F126 1 (Yes)
" 710C Breaker Failure 1 Timer1 Pickup Delay 0 to 65.535 s 0.001 F001 0
" 710D Breaker Failure 1 Use Timer2 0 to 1 --- 1 F126 1 (Yes)
" 710E Breaker Failure 1 Timer2 Pickup Delay 0 to 65.535 s 0.001 F001 0
" 710F Breaker Failure 1 Use Timer3 0 to 1 --- 1 F126 1 (Yes)
" 7110 Breaker Failure 1 Timer3 Pickup Delay 0 to 65.535 s 0.001 F001 0
" 7111 Breaker Failure 1 Breaker Pos1 0 to 4294967295 --- 1 F300 0
" 7113 Breaker Failure 1 Breaker Pos2 0 to 4294967295 --- 1 F300 0
" 7115 Breaker Failure 1 Breaker Test On 0 to 4294967295 --- 1 F300 0
" 7117 Breaker Failure 1 Amp Hiset OpA 0 to 4294967295 --- 1 F300 0
" 7119 Breaker Failure 1 Amp Hiset OpB 0 to 4294967295 --- 1 F300 0
" 711B Breaker Failure 1 Amp Hiset OpC 0 to 4294967295 --- 1 F300 0
" 711D Breaker Failure 1 Amp Loset OpA 0 to 4294967295 --- 1 F300 0
" 711F Breaker Failure 1 Amp Loset OpB 0 to 4294967295 --- 1 F300 0
" 7121 Breaker Failure 1 Amp Loset OpC 0 to 4294967295 --- 1 F300 0
" 7123 Breaker Failure 1 Loset Time Delay 0 to 65.535 s 0.001 F001 0
" 7124 Breaker Failure 1 Trip Dropout Time Delay 0 to 65.535 s 0.001 F001 0
" 7125 Breaker Failure 1 Retrip Time Delay 0 to 65.535 s 0.001 F001 0
" 7126 Breaker Failure 1 Block 0 to 4294967295 --- 1 F300 0
" 7128 Breaker Failure 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 7129 Breaker Failure 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 712A Reserved (6 items) 0 to 65535 --- 1 F001 0
" 7130 ...Repeated for Breaker Failure 2
" 7160 ...Repeated for Breaker Failure 3
" 7190 ...Repeated for Breaker Failure 4
" 71C0 ...Repeated for Breaker Failure 5
" 71F0 ...Repeated for Breaker Failure 6
" 7220 ...Repeated for Breaker Failure 7
" 7250 ...Repeated for Breaker Failure 8
" 7280 ...Repeated for Breaker Failure 9
" 72B0 ...Repeated for Breaker Failure 10
" 72E0 ...Repeated for Breaker Failure 11
" 7310 ...Repeated for Breaker Failure 12
" 7340 ...Repeated for Breaker Failure 13
" 7370 ...Repeated for Breaker Failure 14
" 73A0 ...Repeated for Breaker Failure 15
" 73D0 ...Repeated for Breaker Failure 16
" 7400 ...Repeated for Breaker Failure 17
" 7430 ...Repeated for Breaker Failure 18
Products Address Register name Range Units Step Format Default
