2-114 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 7733 ...Repeated for Disconnect Switch 20
" 7734 ...Repeated for Disconnect Switch 21
" 7735 ...Repeated for Disconnect Switch 22
" 7736 ...Repeated for Disconnect Switch 23
" 7737 ...Repeated for Disconnect Switch 24
Disconnect (Breaker) Switch Commands (Read/Write Command) (8, 12, 16, or 24 Modules)
All except B90 7740 Disconnect Switch 1 Command 0 to 11 --- 1 F282 0 (CANCEL)
" 7741 ...Repeated for Disconnect Switch 2
" 7742 ...Repeated for Disconnect Switch 3
" 7743 ...Repeated for Disconnect Switch 4
" 7744 ...Repeated for Disconnect Switch 5
" 7745 ...Repeated for Disconnect Switch 6
" 7746 ...Repeated for Disconnect Switch 7
" 7747 ...Repeated for Disconnect Switch 8
B30, C60, C70,
D60, F35, F60,
L90, N60, T35,
T60
7748 ...Repeated for Disconnect Switch 9
" 7749 ...Repeated for Disconnect Switch 10
" 774A ...Repeated for Disconnect Switch 11
" 774B ...Repeated for Disconnect Switch 12
B30, C60, D60,
F35, F60, L90,
N60, T35, T60
774C ...Repeated for Disconnect Switch 13
" 774D ...Repeated for Disconnect Switch 14
" 774E ...Repeated for Disconnect Switch 15
" 774F ...Repeated for Disconnect Switch 16
B30, C60, F35,
L90, N60, T35,
T60
7750 ...Repeated for Disconnect Switch 17
" 7751 ...Repeated for Disconnect Switch 18
" 7752 ...Repeated for Disconnect Switch 19
" 7753 ...Repeated for Disconnect Switch 20
" 7754 ...Repeated for Disconnect Switch 21
" 7755 ...Repeated for Disconnect Switch 22
" 7756 ...Repeated for Disconnect Switch 23
" 7757 ...Repeated for Disconnect Switch 24
Thermal Overload Protection (Read/Write Settings) (2 Modules)
All except B90,
C30, M60
7788 Thermal Protection 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 7789 Thermal Protection 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
" 778A Thermal Protection 1 Base Current 0.2 to 3 pu 0.01 F001 80
" 778B Thermal Protection 1 K Factor 1 to 1.2 --- 0.05 F001 110
" 778C Thermal Protection 1 Trip Time Constant 0 to 1000 min. 1 F001 45
" 778D Thermal Protection 1 Reset Time Constant 0 to 1000 min. 1 F001 45
" 778E Thermal Protection 1 Minimum Reset Time 0 to 1000 min. 1 F001 20
" 778F Thermal Protection 1 Reset 0 to 4294967295 --- 1 F300 0
" 7791 Thermal Protection 1 Block 0 to 4294967295 --- 1 F300 0
" 7793 Thermal Protection 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
Products Address Register name Range Units Step Format Default
