2-122 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 7EC9 Dist Zbg Ang -359.9 to 0 degree 0.1 F002 0
" 7ECA Dist Zcg Mag 0 to 655.35 ohm 0.01 F001 0
" 7ECB Dist Zcg Ang -359.9 to 0 degree 0.1 F002 0
Neutral Overvoltage (Read/Write Grouped Setting) (3 Modules)
All except B90,
C30, N60, T35
7F00 Neutral Overvoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 7F01 Neutral Overvoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
" 7F02 Neutral Overvoltage 1 Pickup 0.004 to 3 pu 0.001 F001 300
" 7F03 Neutral Overvoltage 1 Pickup Delay 0 to 600 s 0.01 F001 100
" 7F04 Neutral Overvoltage 1 Reset Delay 0 to 600 s 0.01 F001 100
" 7F05 Neutral Overvoltage 1 Block 0 to 4294967295 --- 1 F300 0
" 7F07 Neutral Overvoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 7F08 Neutral Overvoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 7F09 Neutral Overvoltage 1 Curves 0 to 3 --- 1 F116 0 (Definite
Time)
" 7F0A Reserved (7 items) 0 to 65535 --- 1 F001 0
" 7F11 ...Repeated for Neutral Overvoltage 2
" 7F22 ...Repeated for Neutral Overvoltage 3
Auxiliary Undervoltage (Read/Write Grouped Setting) (3 Modules)
C60, D30, D60,
F35, F60, G30,
G60, L30, L60,
L90, M60, T60
7F60 Auxiliary Undervoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 7F61 Auxiliary Undervoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
" 7F62 Auxiliary Undervoltage 1 Pickup 0.004 to 3 pu 0.001 F001 700
" 7F63 Auxiliary Undervoltage 1 Delay 0 to 600 s 0.01 F001 100
" 7F64 Auxiliary Undervoltage 1 Curve 0 to 1 --- 1 F111 0 (Definite
Time)
" 7F65 Auxiliary Undervoltage 1 Minimum Voltage 0 to 3 pu 0.001 F001 100
" 7F66 Auxiliary Undervoltage 1 Block 0 to 4294967295 --- 1 F300 0
" 7F68 Auxiliary Undervoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 7F69 Auxiliary Undervoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 7F6A Reserved (7 items) 0 to 65535 --- 1 F001 0
" 7F71 ...Repeated for Auxiliary Undervoltage 2
" 7F82 ...Repeated for Auxiliary Undervoltage 3
Auxiliary Overvoltage (Read/Write Grouped Setting) (1, 2, or 3 Modules)
All except B90,
C30, N60, T35
7FA0 Auxiliary Overvoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 7FA1 Auxiliary Overvoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
" 7FA2 Auxiliary Overvoltage 1 Pickup 0.004 to 3 pu 0.001 F001 300
" 7FA3 Auxiliary Overvoltage 1 Pickup Delay 0 to 600 s 0.01 F001 100
" 7FA4 Auxiliary Overvoltage 1 Reset Delay 0 to 600 s 0.01 F001 100
" 7FA5 Auxiliary Overvoltage 1 Block 0 to 4294967295 --- 1 F300 0
" 7FA7 Auxiliary Overvoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 7FA8 Auxiliary Overvoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 7FA9 Reserved (8 items) 0 to 65535 --- 1 F001 0
B30, C70, C60,
D60, F35, F60,
G30 G60, L90,
M60, T60
7FB1 ...Repeated for Auxiliary Overvoltage 2
Products Address Register name Range Units Step Format Default
