2-124 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 8196 Direct Analog Input 12 Value 0 to 2147483647 --- 1 F060 0
" 8198 Direct Analog Input 13 Value 0 to 2147483647 --- 1 F060 0
" 819A Direct Analog Input 14 Value 0 to 2147483647 --- 1 F060 0
" 819C Direct Analog Input 15 Value 0 to 2147483647 --- 1 F060 0
" 819E Direct Analog Input 16 Value 0 to 2147483647 --- 1 F060 0
" 81A0 Direct Analog Input 17 Value 0 to 2147483647 --- 1 F060 0
" 81A2 Direct Analog Input 18 Value 0 to 2147483647 --- 1 F060 0
" 81A4 Direct Analog Input 19 Value 0 to 2147483647 --- 1 F060 0
" 81A6 Direct Analog Input 20 Value 0 to 2147483647 --- 1 F060 0
" 81A8 Direct Analog Input 21 Value 0 to 2147483647 --- 1 F060 0
" 81AA Direct Analog Input 22 Value 0 to 2147483647 --- 1 F060 0
" 81AC Direct Analog Input 23 Value 0 to 2147483647 --- 1 F060 0
" 81AE Direct Analog Input 24 Value 0 to 2147483647 --- 1 F060 0
" 81B0 Direct Analog Input 25 Value 0 to 2147483647 --- 1 F060 0
" 81B2 Direct Analog Input 26 Value 0 to 2147483647 --- 1 F060 0
" 81B4 Direct Analog Input 27 Value 0 to 2147483647 --- 1 F060 0
" 81B6 Direct Analog Input 28 Value 0 to 2147483647 --- 1 F060 0
" 81B8 Direct Analog Input 29 Value 0 to 2147483647 --- 1 F060 0
" 81BA Direct Analog Input 30 Value 0 to 2147483647 --- 1 F060 0
" 81BC Direct Analog Input 31 Value 0 to 2147483647 --- 1 F060 0
" 81BE Direct Analog Input 32 Value 0 to 2147483647 --- 1 F060 0
Temp Monitor Actual Values (Read Only Non-Volatile)
All 81C0 Reserved Register T1 -55 to 125 C 1 F002 -55
" 81C1 Reserved Register T2 -55 to 125 C 1 F002 125
" 81C2 Reserved Register T3 -2147483647 to
2147483647
--- 1 F004 0
" 81C4 Reserved Register T4 0 to 4294967295 --- 1 F003 0
" 81C6 Reserved Register T5 0 to 4294967295 --- 1 F003 0
" 81C8 Reserved Register T6 0 to 4294967295 --- 1 F003 0
" 81CA Reserved Register T7 0 to 4294967295 --- 1 F003 0
" 81CC Reserved Register T8 0 to 4294967295 --- 1 F003 0
Summator Actual Values (Read Only) (6 Modules)
N60 81D0 Summator 1 Actual Value –9999999999 to
9999999999
--- 1 F060 0
" 81D2 Summator 2 Actual Value –9999999999 to
9999999999
--- 1 F060 0
" 81D4 Summator 3 Actual Value –9999999999 to
9999999999
--- 1 F060 0
" 81D6 Summator 4 Actual Value –9999999999 to
9999999999
--- 1 F060 0
" 81D8 Summator 5 Actual Value –9999999999 to
9999999999
--- 1 F060 0
" 81DA Summator 6 Actual Value –9999999999 to
9999999999
--- 1 F060 0
Digitizer Settings (Read/Write) (5 Modules)
N60 8260 Digitizer 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 8261 Digitizer 1 Source Input 0 to 65535 --- 1 F600 0
" 8262 Digitizer 1 Limit Setting 0.05 to 90 pu 0.001 F003 1000
" 8264 Reserved (4 items) 0 to 65535 --- 1 F001 0
Products Address Register name Range Units Step Format Default
