GE b30 Communications Guide

2-126 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
EGD Slow Production (Read/Write Setting) (2 Modules)
B30, C30, C60,
F35, F60, G30,
G60, M60, T35,
T60
8468 EGD Slow Producer Exchange 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 8469 EGD Fast Producer Exchange 1 Destination 0 to 4294967295 --- 1 F003 0
" 846B EGD Slow Producer Exchange 1 Data Rate 500 to 1000 ms 50 F001 1000
" 846C EGD Slow Producer Exchange 1 Data Item
1 (50 items)
0 to 65535 --- 1 F001 0
" 849E Reserved (50 items) --- --- --- F001 0
" 84D0 ...Repeated for EGD Slow Producer
Exchange 2
Direct Integers (Read/Write Setting) (16 Modules)
N60 8540 Direct Integer Output 1 Value 0 to 65535 --- 1 F612 0
" 8541 Direct Integer Output 1 Trigger 0 to 4294967295 --- 1 F300 0
" 8543 Direct Integer Input 1 Device 0 to 16 --- 1 F001 0
" 8544 Direct Integer Input 1 Number 0 to 16 --- 1 F001 0
" 8545 Direct Integer Input 1 Default Value 0 to 4294967295 --- 1 F003 1000
" 8547 Direct Integer Input 1 Mode 0 to 1 --- 1 F491 0 (Default
Value)
" 8548 Direct Integer Reserved 0 to 65535 --- 1 F003 0
" 854A ...Repeated for Direct Integer Output 2
" 8554 ...Repeated for Direct Integer Output 3
" 855E ...Repeated for Direct Integer Output 4
" 8568 ...Repeated for Direct Integer Output 5
" 8572 ...Repeated for Direct Integer Output 6
" 857C ...Repeated for Direct Integer Output 7
" 8586 ...Repeated for Direct Integer Output 8
" 8590 ...Repeated for Direct Integer Output 9
" 859A ...Repeated for Direct Integer Output 10
" 85A4 ...Repeated for Direct Integer Output 11
" 85AE ...Repeated for Direct Integer Output 12
" 85B8 ...Repeated for Direct Integer Output 13
" 85C2 ...Repeated for Direct Integer Output 14
" 85CC ...Repeated for Direct Integer Output 15
" 85D6 ...Repeated for Direct Integer Output 16
Breaker Failure (Read/Write Grouped Setting) (2, 3, 4, or 6 Modules)
B30, C60, C70,
D60, F60, G60,
L30, L60, L90,
M60, T60
8600 Breaker Failure 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 8601 Breaker Failure 1 Mode 0 to 1 --- 1 F157 0 (3-Pole)
" 8602 Breaker Failure 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
" 8603 Breaker Failure 1 Amp Supervision 0 to 1 --- 1 F126 1 (Yes)
" 8604 Breaker Failure 1 Use Seal-In 0 to 1 --- 1 F126 1 (Yes)
" 8605 Breaker Failure 1 Three Pole Initiate 0 to 4294967295 --- 1 F300 0
" 8607 Breaker Failure 1 Block 0 to 4294967295 --- 1 F300 0
" 8609 Breaker Failure 1 Phase Amp Supv Pickup 0.02 to 30 pu 0.001 F001 1050
" 860A Breaker Failure 1 Neutral Amp Supv Pickup 0.02 to 30 pu 0.001 F001 1050
" 860B Breaker Failure 1 Use Timer 1 0 to 1 --- 1 F126 1 (Yes)
Products Address Register name Range Units Step Format Default
