2-140 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 9935 Breaker Restrike 1 Reset Delay 0 to 65.535 s 0.001 F001 100
" 9936 Breaker Restrike 1 HF Detect 0 to 1 --- 1 F102 1 (Enabled)
" 9937 Breaker Restrike 1 Breaker Open 0 to 4294967295 --- 1 F300 0
" 9939 Breaker Restrike 1 Open Command 0 to 4294967295 --- 1 F300 0
" 993B Breaker Restrike 1 Close Command 0 to 4294967295 --- 1 F300 0
" 993D Breaker Restrike 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 993E Breaker Restrike 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 993F Reserved (2 items) --- --- --- F002 0
" 9941 ...Repeated for Breaker Restrike 2
B30, C60, C70,
F35, F60, T60
9952 ...Repeated for Breaker Restrike 3
Teleprotection Inputs/Outputs Commands (Read/Write Command)
All except B90,
L30, L90
99EF Teleprotection Clear Lost Packets 0 to 1 --- 1 F126 0 (No)
Teleprotection Inputs/Outputs (Read/Write Settings)
All except B90,
L30, L90
99F0 Teleprotection Function 0 to 1 --- 1 F102 0 (Disabled)
" 99F1 Teleprotection Number of Terminals 2 to 3 --- 1 F001 2
" 99F2 Teleprotection Number of Channels 1 to 2 --- 1 F001 1
" 99F3 Teleprotection Local Relay ID 0 to 63 --- 1 F001 0
" 99F4 Teleprotection Terminal 1 ID 0 to 63 --- 1 F001 0
" 99F5 Teleprotection Terminal 2 ID 0 to 63 --- 1 F001 0
" 99F6 Reserved (10 items) 0 to 1 --- 1 F001 0
" 9A00 Teleprotection Input 1-n Default States (16
items)
0 to 3 --- 1 F086 0 (Off)
" 9A10 Teleprotection Input 2-n Default States (16
items)
0 to 3 --- 1 F086 0 (Off)
" 9A20 Teleprotection Output 1-n Operand (16
items)
0 to 4294967295 --- 1 F300 0
" 9A40 Teleprotection Output 2-n Operand (16
items)
0 to 4294967295 --- 1 F300 0
Teleprotection Channel Tests (Read Only)
All except B90,
L30, L90
9AA0 Teleprotection Channel 1 Status 0 to 2 --- 1 F134 1 (OK)
" 9AA1 Teleprotection Channel 1 Number of Lost
Packets
0 to 65535 --- 1 F001 0
" 9AA2 Teleprotection Channel 2 Status 0 to 2 --- 1 F134 2 (n/a)
" 9AA3 Teleprotection Channel 2 Number of Lost
Packets
0 to 65535 --- 1 F001 0
" 9AA4 Teleprotection Network Status 0 to 2 --- 1 F134 2 (n/a)
" 9AAF Teleprotection Channel 1 Input States 0 to 1 --- 1 F500 0
" 9AB0 Teleprotection Channel 2 Input States 0 to 1 --- 1 F500 0
" 9AC0 Teleprotection Input 1 States, 1 per register
(16 items)
0 to 1 --- 1 F108 0 (Off)
" 9AD0 Teleprotection Input 2 States, 1 per register
(16 items)
0 to 1 --- 1 F108 0 (Off)
Capacitor Control Settings (Read/Write Setting) (3 Modules)
C70 9B00 Capacitor Control 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 9B01 Capacitor Control 1 Set Remote 1 0 to 4294967295 --- 1 F300 0
" 9B03 Capacitor Control 1 Set Remote 2 0 to 4294967295 --- 1 F300 0
" 9B05 Capacitor Control 1 Set Local 1 0 to 4294967295 --- 1 F300 0
Products Address Register name Range Units Step Format Default
