CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-157
2
" ABD2 ...Repeated for IEC 61850 GGIO4 Analog
Input 15
" ABD9 ...Repeated for IEC 61850 GGIO4 Analog
Input 16
" ABE0 ...Repeated for IEC 61850 GGIO4 Analog
Input 17
" ABE7 ...Repeated for IEC 61850 GGIO4 Analog
Input 18
" ABEE ...Repeated for IEC 61850 GGIO4 Analog
Input 19
" ABF5 ...Repeated for IEC 61850 GGIO4 Analog
Input 20
" ABFC ...Repeated for IEC 61850 GGIO4 Analog
Input 21
" AC03 ...Repeated for IEC 61850 GGIO4 Analog
Input 22
" AC0A ...Repeated for IEC 61850 GGIO4 Analog
Input 23
" AC11 ...Repeated for IEC 61850 GGIO4 Analog
Input 24
" AC18 ...Repeated for IEC 61850 GGIO4 Analog
Input 25
" AC1F ...Repeated for IEC 61850 GGIO4 Analog
Input 26
" AC26 ...Repeated for IEC 61850 GGIO4 Analog
Input 27
" AC2D ...Repeated for IEC 61850 GGIO4 Analog
Input 28
" AC34 ...Repeated for IEC 61850 GGIO4 Analog
Input 29
" AC3B ...Repeated for IEC 61850 GGIO4 Analog
Input 30
" AC42 ...Repeated for IEC 61850 GGIO4 Analog
Input 31
" AC49 ...Repeated for IEC 61850 GGIO4 Analog
Input 32
IEC 61850 Server Configuration (Read/Write Settings)
All AC51 IEC 61850 Server Data Scanning Function 0 to 1 --- 1 F102 0 (Disabled)
" AC52 MMS TCP Connection Timeout 10 to 7200 s 10 F001 120
Contact Inputs (Read/Write Setting) (120 Modules)
All AC58 Contact Input 1 Name --- --- --- F636 “Cont Ip 1“
" AC62 Contact Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" AC63 Contact Input 1 Debounce Time 0 to 16 ms 0.5 F001 60
" AC64 ...Repeated for Contact Input 2
" AC70 ...Repeated for Contact Input 3
" AC7C ...Repeated for Contact Input 4
" AC88 ...Repeated for Contact Input 5
" AC94 ...Repeated for Contact Input 6
" ACA0 ...Repeated for Contact Input 7
" ACAC ...Repeated for Contact Input 8
" ACB8 ...Repeated for Contact Input 9
" ACC4 ...Repeated for Contact Input 10
" ACD0 ...Repeated for Contact Input 11
Products Address Register name Range Units Step Format Default
