CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-171
2
" C97C ...Repeated for Direct Input 60
" C980 ...Repeated for Direct Input 61
" C984 ...Repeated for Direct Input 62
" C988 ...Repeated for Direct Input 63
" C98C ...Repeated for Direct Input 64
Direct Input/Output Alarms (Read/Write Setting)
All except L30,
L90
CAD0 Direct Input/Output Channel 1 CRC Alarm
Function
0 to 1 --- 1 F102 0 (Disabled)
" CAD1 Direct Input/Output Channel 1 CRC Alarm
Message Count
100 to 10000 --- 1 F001 600
" CAD2 Direct Input/Output Channel 1 CRC Alarm
Threshold
1 to 1000 --- 1 F001 10
" CAD3 Direct Input/Output Channel 1 CRC Alarm
Events
0 to 1 --- 1 F102 0 (Disabled)
" CAD4 Reserved (4 items) 1 to 1000 --- 1 F001 10
" CAD8 Direct Input/Output Channel 2 CRC Alarm
Function
0 to 1 --- 1 F102 0 (Disabled)
" CAD9 Direct Input/Output Channel 2 CRC Alarm
Message Count
100 to 10000 --- 1 F001 600
" CADA Direct Input/Output Channel 2 CRC Alarm
Threshold
1 to 1000 --- 1 F001 10
" CADB Direct Input/Output Channel 2 CRC Alarm
Events
0 to 1 --- 1 F102 0 (Disabled)
" CADC Reserved (4 items) 1 to 1000 --- 1 F001 10
" CAE0 Direct Input/Output Channel 1 Unreturned
Messages Alarm Function
0 to 1 --- 1 F102 0 (Disabled)
" CAE1 Direct Input/Output Channel 1 Unreturned
Messages Alarm Msg Count
100 to 10000 --- 1 F001 600
" CAE2 Direct Input/Output Channel 1 Unreturned
Messages Alarm Threshold
1 to 1000 --- 1 F001 10
" CAE3 Direct Input/Output Channel 1 Unreturned
Messages Alarm Events
0 to 1 --- 1 F102 0 (Disabled)
" CAE4 Reserved (4 items) 1 to 1000 --- 1 F001 10
" CAE8 Direct Input/Output Channel 2 Unreturned
Messages Alarm Function
0 to 1 --- 1 F102 0 (Disabled)
" CAE9 Direct Input/Output Channel 2 Unreturned
Messages Alarm Msg Count
100 to 10000 --- 1 F001 600
" CAEA Direct Input/Output Channel 2 Unreturned
Messages Alarm Threshold
1 to 1000 --- 1 F001 10
" CAEB Direct Input/Output Channel 2 Unreturned
Messages Alarm Events
0 to 1 --- 1 F102 0 (Disabled)
" CAEC Reserved (4 items) 1 to 1000 --- 1 F001 10
Contact Outputs (Read/Write Setting) (72 Modules)
All CAF0 Contact Output 1 Name --- --- --- F636 “Cont Op 1"
" CAFA Contact Output 1 Operation 0 to 4294967295 --- 1 F300 0
" CAFC Contact Output 1 Seal In 0 to 4294967295 --- 1 F300 0
" CAFE Latching Output 1 Reset 0 to 4294967295 --- 1 F300 0
" CB00 Contact Output 1 Events 0 to 1 --- 1 F102 1 (Enabled)
" CB01 Latching Output 1 Type 0 to 1 --- 1 F090 0 (Operate-
dominant)
" CB02 Reserved --- --- --- F001 0
" CB03 ...Repeated for Contact Output 2
