CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-15
2
Graphical Front Panel Settings (Read/Write Setting)
All 0430 GFP Home Page Content (10 items) 0 to 27 --- 1 F647 0 (Product
Information)
" 043A GFP Date Format 0 to 7 --- 1 F648 0 (yyyy-mm-
dd)
" 043B GFP Time Format 0 to 1 --- 1 F649 0 (hh:mm:ss)
" 043C GFP Rolling Mode Delay 0 to 900 seconds 1 F001 300
" 043D GFP Rolling Mode Pages (10 items) 0 to 27 --- 1 F647 0 (Product
Information)
" 0447 GFP Number of Rolling Mode Pages 1 to 10 --- 1 F001 1
" 0448 GFP Automatic Annunciator Recall 0 to 1 --- 1 F102 1 (Enabled)
" 0449 GFP Screen Saver Delay 0 to 900 seconds 1 F001 300
" 044A GFP Screen Saver Intensity 0 to 3 --- 1 F650 3 (30 %)
" 044B GFP Configurable Navigation Condition (64
items)
0 to 4294967295 --- 1 F300 0
" 04CB GFP Configurable Navigation Activate Page
(64 items)
0 to 27 --- 1 F647 0 (Product
Information)
" 050D GFP Mimic (Single-Line) Diagram Status
Component Operand (32 items)
0 to 4294967295 --- 1 F300 0
" 054F GFP Tabular Metering Status Operand (16
items)
0 to 4294967295 --- 1 F300 0
Graphical Front Panel (Read Only)
All 050B GFP Configurable Navigation Sequence
Number (10 items)
0 to 65535 --- 1 F001 0
" 050C GFP Configurable Navigation Target Page 0 to 27 --- 1 F647 0 (Product
Information)
" 054D GFP Mimic (Single-Line) Diagram Status
Component Packed States
0 to 4294967295 --- 1 F003 0
" 056F GFP Tabular Metering Packed States 0 to 65535 --- 1 F001 0
" 0570 GFP LED Packed States 0 to 65535 --- 1 F001 0
" 0571 GFP Miscellaneous Packed States 0 to 15 --- 1 F652 0 (CLOCK
SYNC)
Graphical Front Panel (Read/Write Command)
All 0575 GFP Reset Command 0 to 1 --- 1 F126 0 (No)
IEC103 Protocol Settings (Read/Write Setting)
All 0582 IEC103 Common ASDU Address 0 to 254 --- 1 F001 0
" 0583 IEC103 Sync Timeout 1 to 1440 min 1 F001 1
IEC103 Binary Inputs (Read/Write Setting) (96 Modules)
All 0584 IEC103 Binary Input 1 FUN 0 to 255 --- 1 F001 0
" 0585 IEC103 Binary Input 1 INF 0 to 255 --- 1 F001 0
" 0586 IEC103 Binary Input 1 Operand 0 to 4294967295 --- 1 F300 0
" 0588 ...Repeated for Binary Input 2
" 058C ...Repeated for Binary Input 3
" 0590 ...Repeated for Binary Input 4
" 0594 ...Repeated for Binary Input 5
" 0598 ...Repeated for Binary Input 6
" 059C ...Repeated for Binary Input 7
" 05A0 ...Repeated for Binary Input 8
" 05A4 ...Repeated for Binary Input 9
" 05A8 ...Repeated for Binary Input 10
