3-152 UR FAMILY – COMMUNICATIONS GUIDE

MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION

3.5.4.2 AC inputs (CT inputs and VT inputs) (ACin)

Uses Beh and NamPlt elements outlined in the Common data objects and attributes table on page 3-29.

3.5.4.3 Breaker control (Bkr)

This element is instantiated in the following products: B30, C30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90, M60,

N60, T35, T60.

Table 3-170: Breaker control data objects

Table 3-171: Breaker control data objects

LNName: BkrCSWI# LDevice inst: System UR element: Breaker Control element #

data obj. data attribute Type FC UR Name Description R/W/C

Mod INC This logical node’s mode R/Ctrl

stVal ENUMERATED ST 1 (on) R

ctlModel CtlModels CF 0 (status only) R

Health INS This logical node’s health R

stVal ENUMERATED ST LPHD1.PhyHealth.stVal R

Pos DPC Breaker position control and status R/Ctrl

stVal CODED ENUM ST Bkr0XCBR#.Pos.stVal R

stSeld BOOLEAN ST The controllable data status is “selected” R

pulseConfig PulseConfig CF R

pulseConfig

.cmdQual

ENUMERATED 0 (pulse) R

pulseConfig.onDur INT32U 2 R

pulseConfig

.offDur

INT32U 0 R

pulseConfig

.numPls

INT32U 1 R

ctlModel CtlModels CF BkrCSWI# Pos ctlModel R/W/C

sboTimeout INT32U CF BkrCSWI# Pos sboTimeout R/W/C

sboClass SboClasses CF 0 (operate-once) R

operTimeout INT32U CF BkrCSWI# Pos operTimeout R/C

LNName: BkrCILO# LDevice inst: System UR element: Breaker Control element #

data obj. data attribute Type FC UR Name Description R/W/C

Mod INC This logical node’s mode R/Ctrl

stVal ENUMERATED ST 1 (on) R

ctlModel CtlModels CF 0 (status only) R

Health INS This logical node’s health R

stVal ENUMERATED ST LPHD1.PhyHealth.stVal R

EnaOpn SPS Enable Open status R

stVal BOOLEAN ST The state of the operand selected by

setting XCBR# INTERLOCK OPN

EnaCls SPS Enable Close status R

stVal BOOLEAN ST Logical OR of the state of the operand

selected by setting XCBR# SYNCCHECK

CLS and the state of the operand selected

by setting XCBR# INTERLOCK CLS

InRef2 ORG XCBR# INTERLOCK OPN setting. R

GEORG R

setSrcRef ObjectReference SP XCBR# INTERLOCK OPN reference to the data attribute to input R/C

VISIBLE

STRING255

SP Reference to the ultimate source

of value selected by setting

XCBR# INTERLOCK OPN

R/C

setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
