CHAPTER 3: IEC 61850 COMMUNICATION MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-191
3
phsθ.zeroDb INT32U CF 0 R
neut CMV R
neut.instCVal Vector MX R
neut.instCVal.mag
.f
FLOAT32 SRC # Neutral THD magnitude R
neut.cVal Vector MX R
neut.cVal.mag.f FLOAT32 SRC # Neutral THD magnitude,
with dead band
R
neut.units Unit CF R
neut.units.SIUnit ENUMERATED 1, the code for dimensionless
(percentage)
R
neut.units
.multiplier
ENUMERATED -2 R
neut.db INT32U CF HThdMHAI#.ThdA.neut.db R/W/C
neut.zeroDb INT32U CF 0 R
HA HWYE Instantiated only in products that
measure current harmonics
R
phsθHar(0) CMV R
phsθHar(0)
.instCVal
Vector MX R
phsθHar(0)
.instCVal.mag.f
FLOAT32 0 R
phsθHar(0).cVal Vector MX R
phsθHar(0).cVal
.mag.f
FLOAT32 0 R
phsθHar(0).units Unit CF R
phsθHar(0).units
.SIUnit
ENUMERATED 1, the code for dimensionless
(percentage)
R
phsθHar(0).units
.multiplier
ENUMERATED -2 R
phsθHar(0).db INT32U CF 0 R
phsθHar(0).zeroDb INT32U CF 0 R
phsθHar(1) CMV R
phsθHar(1)
.instCVal
Vector MX R
phsθHar(1)
.instCVal.mag.f
FLOAT32 0 R
phsθHar(1).cVal Vector MX R
phsθHar(1).cVal
.mag.f
FLOAT32 0 R
phsθHar(1).units Unit CF
R
phsθHar(1).units
.SIUnit
ENUMERATED 1, the code for dimensionless
(percentage)
R
phsθHar(1).units
.multiplier
ENUMERATED -2 R
phsθHar(1).db INT32U CF 0 R
phsθHar(1).zeroDb INT32U CF 0 R
phsθHar(n) CMV R
phsθHar(n)
.instCVal
Vector MX R
phsθHar(n)
.instCVal.mag.f
FLOAT32 SRC # nτ Iφ R
phsθHar(n).cVal Vector MX R
phsθHar(n).cVal
.mag.f
FLOAT32 SRC # nτ Iφ magnitude, with
dead band
R
phsθHar(n).units Unit CF R
phsθHar(n).units
.SIUnit
ENUMERATED 1, the code for dimensionless
(percentage)
R
phsθHar(n).units
.multiplier
ENUMERATED -2 R
phsθHar(n).db INT32U CF HThdMHAI#.HA.phsθHar(n).db R/W/C
phsθHar(n).zeroDb INT32U CF 0 R
LNName: HThdMHAI# LDevice inst: Meter UR element: Harmonics and THD metering
data obj. data attribute Type FC UR Name Description R/W/C
