CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-25
2
" 0B02 ...Repeated for RxGOOSE Boolean 249
" 0B04 ...Repeated for RxGOOSE Boolean 250
" 0B06 ...Repeated for RxGOOSE Boolean 251
" 0B08 ...Repeated for RxGOOSE Boolean 252
" 0B0A ...Repeated for RxGOOSE Boolean 253
" 0B0C ...Repeated for RxGOOSE Boolean 254
" 0B0E ...Repeated for RxGOOSE Boolean 255
" 0B10 ...Repeated for RxGOOSE Boolean 256
Expanded Remote Input/Output Status (Read Only)
All 0B12 Remote Device States, one per register (64
items)
0 to 1 --- 1 F155 0 (Offline)
" 0B52 RxGOOSE Boolean x States, one per
register (256 items)
0 to 1 --- 1 F108 0 (Off)
Element States (Read Only)
All 1000 Element Operate States (66 items) 0 to 65535 --- 1 F502 0
User Displays Actuals (Read Only)
All 1080 Formatted user-definable displays (16
items)
--- --- --- F200 (none)
Modbus User Map Actuals (Read Only)
All 1200 User Map Values (256 items) 0 to 65535 --- 1 F001 0
Direct Analog Input and Output Settings (Read/Write Setting) (32 Modules)
N60 1320 Direct Analog Output 1 Value 0 to 65535 --- 1 F600 0
" 1321 Direct Analog Output 1 Deadband 0 to 1000000000 --- 0.001 F060 1000000
" 1323 Direct Analog Output 1 Trigger 0 to 4294967295 --- 1 F300 0
" 1325 Direct Analog Input 1 Device 0 to 16 --- 1 F001 0
" 1326 Direct Analog Input 1 Number 0 to 32 --- 1 F001 0
" 1327 Direct Analog Input 1 Units --- --- --- F207 (none)
" 1329 Direct Analog Input 1 Default Value –1000000000 to
1000000000
--- 0.001 F060 1000
" 132B Direct Analog Input 1 Mode 0 to 1 --- 1 F491 0 (Default
Value)
" 132C Direct Analog Input 1 PU Base 1 to 2000000 --- 1 F003 1
" 132E ...Repeated for Direct Analog Input and
Output 2
" 133C ...Repeated for Direct Analog Input and
Output 3
" 134A ...Repeated for Direct Analog Input and
Output 4
" 1358 ...Repeated for Direct Analog Input and
Output 5
" 1366 ...Repeated for Direct Analog Input and
Output 6
" 1374 ...Repeated for Direct Analog Input and
Output 7
" 1382 ...Repeated for Direct Analog Input and
Output 8
" 1390 ...Repeated for Direct Analog Input and
Output 9
" 139E ...Repeated for Direct Analog Input and
Output 10
" 13AC ...Repeated for Direct Analog Input and
Output 11
Products Address Register name Range Units Step Format Default

GE b30 Specifications

General

Model	b30
Manufacturer	GE
Coil Voltage	N/A (Solid State Relay)
Coil Power	N/A (Solid State Relay)
Mechanical Life	N/A (Solid State Relay)
Electrical Life	N/A (Solid State Relay)
