4-8 UR FAMILY – COMMUNICATIONS GUIDE
DEVICE PROFILE DOCUMENT CHAPTER 4: DNP COMMUNICATION
4
32 0 Analog Change Event (Variation 0 is
used to request default variation)
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
1 32-Bit Analog Change Event
without Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol. resp.)
17, 28 (index)
2 16-Bit Analog Change Event
without Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol. resp.)
17, 28 (index)
3 32-Bit Analog Change Event with
Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol. resp.)
17, 28 (index)
4 16-Bit Analog Change Event with
Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol. resp.)
17, 28 (index)
5 short floating point Analog Change
Event without Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol. resp.)
17, 28 (index)
7 short floating point Analog Change
Event with Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol. resp.)
17, 28 (index)
34 0 Analog Input Reporting Deadband
(Variation 0 is used to request
default variation)
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited
quantity)
17, 28 (index)
1 16-bit Analog Input Reporting
Deadband
(default – see Note 1)
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited
quantity)
17, 28 (index)
129 (response) 00, 01 (start-stop)
17, 28 (index)
(see Note 2)
2 (write) 00, 01 (start-stop)
07, 08 (limited
quantity)
17, 28 (index)
34
cont’d
2 32-bit Analog Input Reporting
Deadband
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited
quantity)
17, 28 (index)
129 (response) 00, 01 (start-stop)
17, 28 (index)
(see Note 2)
2 (write) 00, 01 (start-stop)
07, 08 (limited
quantity)
17, 28 (index)
3 Short floating point Analog Input
Reporting Deadband
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited
quantity)
17, 28 (index)
129 (response) 00, 01 (start-stop)
17, 28 (index)
(see Note 2)
Object Request Response
Object
no.
Variation
no.
Description Function codes
(dec)
Qualifier codes
(hex)
Function codes
(dec)
Qualifier codes
(hex)
Note 1: A default variation refers to the variation responded when variation 0 is requested and/or in class 0, 1, 2, or 3 scans. The default
variations for object types 1, 2, 20, 21, 22, 23, 30, and 32 are selected via relay settings. See the Communications section in Chapter 5
of the Instruction Manual for details. This optimizes the class 0 poll data size.
Note 2: For static (non-change-event) objects, qualifiers 17 or 28 are only responded when a request is sent with qualifiers 17 or 28,
respectively. Otherwise, static object requests sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01 (for
change-event objects, qualifiers 17 or 28 are always responded.)
Note 3: Cold restarts are implemented the same as warm restarts, meaning that the UR is not restarted, but the DNP process is restarted.
