2-42 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
Direct Integer Actual Values (Read Only) (16 Modules)
N60 2730 Direct Integer Input 1 Actual Value 0 to 4294967295 --- 1 F003 0
" 2732 Direct Integer Input 2 Actual Value 0 to 4294967295 --- 1 F003 0
" 2734 Direct Integer Input 3 Actual Value 0 to 4294967295 --- 1 F003 0
" 2736 Direct Integer Input 4 Actual Value 0 to 4294967295 --- 1 F003 0
" 2738 Direct Integer Input 5 Actual Value 0 to 4294967295 --- 1 F003 0
" 273A Direct Integer Input 6 Actual Value 0 to 4294967295 --- 1 F003 0
" 273C Direct Integer Input 7 Actual Value 0 to 4294967295 --- 1 F003 0
" 273E Direct Integer Input 8 Actual Value 0 to 4294967295 --- 1 F003 0
" 2740 Direct Integer Input 9 Actual Value 0 to 4294967295 --- 1 F003 0
" 2742 Direct Integer Input 10 Actual Value 0 to 4294967295 --- 1 F003 0
" 2744 Direct Integer Input 11 Actual Value 0 to 4294967295 --- 1 F003 0
" 2746 Direct Integer Input 12 Actual Value 0 to 4294967295 --- 1 F003 0
" 2748 Direct Integer Input 13 Actual Value 0 to 4294967295 --- 1 F003 0
" 274A Direct Integer Input 14 Actual Value 0 to 4294967295 --- 1 F003 0
" 274C Direct Integer Input 15 Actual Value 0 to 4294967295 --- 1 F003 0
" 274E Direct Integer Input 16 Actual Value 0 to 4294967295 --- 1 F003 0
Source Current THD and Harmonics (Read Only)
(2, 4, or 6 Modules)
C70, D60, F35,
F60, G30, G60,
L30, L90, N60,
T60
2800 Ia THD for Source 1 0 to 99.9 --- 0.1 F001 0
" 2801 Ia Harmonics for Source 1 - 2nd to 25th (24
items)
0 to 99.9 --- 0.1 F001 0
" 2821 Ib THD for Source 1 0 to 99.9 --- 0.1 F001 0
" 2822 Ib Harmonics for Source 1 - 2nd to 25th (24
items)
0 to 99.9 --- 0.1 F001 0
" 283A Reserved (8 items) 0 to 0.1 --- 0.1 F001 0
" 2842 Ic THD for Source 1 0 to 99.9 --- 0.1 F001 0
" 2843 Ic Harmonics for Source 1 - 2nd to 25th (24
items)
0 to 99.9 --- 0.1 F001 0
" 285B Reserved (8 items) 0 to 0.1 --- 0.1 F001 0
" 2863 ...Repeated for Source 2
C70, D60, F35,
F60, G30, G60,
L90, N60, T60
28C6 ...Repeated for Source 3
" 2929 ...Repeated for Source 4
C70, F35, N60,
T60
298C ...Repeated for Source 5
" 29EF ...Repeated for Source 6
Synchrocheck Actual Values (Read Only) (4, 6, or 10 Modules)
C60, D30, D60,
F60, G30, G60,
L30, L60, L90,
N60, T60
2A60 Synchrocheck 1 Delta Voltage -1000000000000 to
1000000000000
V1F0600
" 2A62 Synchrocheck 1 Delta Phase 0 to 180
(not 0 to 359.9)
degrees 0.1 F001 0
" 2A63 Synchrocheck 1 Synchscope 0 to 360
(not 0 to 359.9)
degrees 0.1 F001 0
" 2A64 Synchrocheck 1 Delta Frequency 0 to 655.35 Hz 0.01 F001 0
" 2A65 Synchrocheck 1 V1 Mag -1000000000000 to
1000000000000
V1F0600
