GE CFE29TS

68
FZ
Display
FF
Display
Mode Comments
00 61
Compressor Relay Test
Turns on the Load
00 63
IMX Power Relay Test (Normally Closed
Relay)
Turns on the Load
00 64
Double Drawer Mullion heater Test
Turns on the Load
00 65
DB Icemaker Water Valve Test
Turns on the Load
00 66
DB Icemaker Rake Motor Test
Turns on the Load
00 67
DB Hot Water valve Test
Turns on the Load
00 68
DB Water Valve Test
Turns on the Load
00 69
Hot Water heater Test
Turns on the Load
00 70
Read Left FF Door Status
Returns the
Status (0 = Closed, 1 = Open)
00 71
Read Right FF Door Status
Returns the
Status (0 = Closed, 1 = Open)
00 72
Read FZ door Status
Returns the
Status (0 = Closed, 1 = Open)
00 73
Read Conv Drawer/ IM Input Status
Returns the
Status (0 = Closed, 1 = Open)
00 74
Read MB Icemaker Rake Status
Returns the
Status (0 = not home, 1 = Home)
00 75
Read MB Icemaker Arm Status
Returns the
Status (0 = not Full, 1 = Full)
00 76
Read DB Icemaker Rake Status
Returns the
Status (0 = not home, 1 = Home)
00 77
Read DB Icemaker Arm Status
Returns the
Status (0 = not Full, 1 = Full)
00 78
Read DB Cold Water Cup Switch
Returns the
Status (0 = Not Pressed)
00 79
Read DB Hot Water Cup Switch
Returns the
Status (0 = Not Pressed)
00 80
Read DB Hot Water Level Switch 1
Returns the
Status (0 = Not Full)
00 81
Read DB Hot Water Level Switch 2
Returns the
Status (0 = Not Full)
MB = Main Board, Cabinet
DB = Door Board, LH Door
Service Diagnostics Tests
