GE CFE29TS

69
FZ
Display
FF
Display
Mode Comments
00 84
Turn ON DB Fill Tube Heater
Turns on the Load
00 85
Turn on DB Recess Heater
Turns on the Load
00 86
Turn on Vertical Mullion Heater
Turns on the Load
00 87
Turn On Hot Water LED
Turns on the Load
00 88
Turn on DB heater
Turns on the Load
00 89
Turn on Ice Gasket Heater
Turns on the Load
00 91
Turn on FF Lights
Turns the lights on at 100% Duty Cycle
00 92
Turn on FZ Lights
Turns the lights on at 100% Duty Cycle
00 93
FZ Defrost Heater Test with Feedback
The heater will come on and the evaporator temperature will be
displayed
00 94
FF Defrost heater Test with Feedback
The heater will come on and the evaporator temperature will be
displayed
00 95
FF Cooling Test
In this test, the following loads will be controlled
•
Valve = Position A
•
Compressor = High
•
Condenser Fan High
•
FF Fan = Low
•
The test will return the FF Evaporator Temp
00 96
FZ Cooling Test
In this test, the following loads will be controlled
•
Valve = Position B
•
Compressor = High
•
Condenser Fan High
•
FZ Fan = Low
•
The test will return the FZ Evaporator Temp
00 97
DB Icemaker Heater Test
Turns on the Load
00 98
MB Icemaker Heater Test
Turns on the Load
00 99
DB Icemaker Full Cycle Test
Icemaker Heater will come on and the Instantaneous Ice Mold Body
Thermistor reading will be returned.
01 00
MB Icemaker Full Cycle Test
IM heater comes on & the Icemaker Mold Body reading returned
MB = Main Board, Cabinet
DB = Door Board, LH Door
Service Diagnostics Tests
