7-2 Issue 01, 04/05 CL 5
Specifications Instrument Specifications
This chapter lists the features and specifications of your CL 5 including:
• Instrument Specifications (Section 7.1)
• Features of the Optional A-Scan (Section 7.2)
• Features of the Velocity Measurement Option (Section 7.3)
• Features of the Optional Data Recorder (Section 7.4)
• Probe Specifications (Section 7.5)
7.1 Instrument Specifications
Operating Principle: Ultrasonic, pulse echo measurement method
Measuring Range: 0.006 to 20.00 inch depending on probe and material
0.16 to 500 mm
Measuring Resolution: inch 0.001 default (selectable 0 .0001, 0.001, 0.01 inch)
mm 0.01 default (selectable 0.001, 0.01, 0.1 mm)
Material Velocity Range: 0.03937 to 0.78736 in/µs
1000 to 19999 m/s
Material Velocity Resolution: 0.00001 in/µs
0.1 m/s
