CL 5 Issue 01, 04/05 7-3
Instrument Specifications Specifications
Units: Inch or millimeter
Calibration: Enter velocity or thickness
Contact: One point or Two point calibration
Delay: One point
Pulser:
Excitation Pulse: Spike Pulser
Voltage: 100 V into 50 ohm load, using 20 MHz Scope
Receiver
Bandwidth: 1.0 to 10 MHz @ -3 dB
Gain: Automatic Gain Control
Display Type: High Resolution: Graphical LCD 64 x 128 Pixels,
2.25 ´ 2.56 (40 ´ 57 mm) with backlight and adjustable contrast.
Update Rate: 4 Hz or 8 Hz (User Selectable)
Thickness Value Display: 5 digit 0.75 (19 mm) high NORMAL MODE
5 digit 0.25 (6 mm) high with display of A-SCAN)
