7-12 170 Series Monitor Revision C
2000947-004
Serviceable Assemblies: Transducer Plug Replacement Kits
Table 7-5. FECG Cable Wiring
Pin Number Pin Length Description Wire Color
1 short
2 short ECG Enable Blue and #26 AWG Blue Jumper
3 LONG Ground #26 AWG Blue Jumper
4 short
5 short
6 short LA (red terminal) White/Black
7 short RA (green terminal) White
8 short Shield #26 AWG Green
9 short
10 short
11 short
12 short RL (plate) White/Red
