GE CT ProSpeed Series

GE MEDICAL SYSTEMS CT PROSPEED SERIES INSTALLATION
2124011
ii
REV 1
CONTENTS
SITE PREP ARA TION FOR INST ALLA TION (T ab 1)
SITE PREP ARATION
REQUIRED TOOLS AND TEST EQUIPMENT CHECK
GANTRY AND T ABLE INST ALLA TION ANS LEVELING (T ab 2)
FL OOR AND ROOM PREP ARATION
INSTALLA TION AND LEVELING OF GANTRY
INSTALLA TION AND LEVELING OF T ABLE
INST ALLING OF REMAINING COMPONENTS (T ab 3)
POWER DISTRIBUTION UNIT (PDU)
OPERA TOR CONSOLE (Qj-b TYPE)
OPERA TOR CONSOLE (Zj/Zj-a TYPE)
OPTION B OARD L OCATIONS
MOD INST ALLATION
LASER IMAGER INST ALLATION
DIAGNOSTIC CONSOLE
SYSTEM POWER , GROUND AND CABLE INTER-CONNECTION (Tab 4)
GENERAL SYSTEM CABLING INSTRUCTIONS AND REFERENCE
CABLE INTER-CONNECTION (Qj)
SCAN ROOM X-RA Y ON LIGHT AND SYSTEM POWER ON LIGHT
SCAN ROOM DOOR SAFETY
CABLE INTER-CONNECTION (Zj)
SCAN ROOM X-RA Y ON LIGHT
ANCHORING OF GANTRY AND T ABLE (T ab 5)
PRECAUTION
ANCHORING
INSTALLA TION COMPLETION (T ab 6)
INSTALLA TION OF SUB SYSTEM TRIM CO VER P ANELS
DAT A PLA TE AND LABEL (Qj/Qj-b TYPE)
DAT A PLA TE AND LABEL (Zj/Zj-a TYPE)
OC EMBLEM
GANTRY EMBLEM
FINAL ROOM CLEAN-UP
SYSTEM COMPONENT IDENTIFICA TION (T ab 7)
COMPONENT IDENTIFICA TION
TYPICAL INST ALLA TION AND CHECK/ADJUSTMENT PROCEDURE (T ab 8)
GENERAL
PROCEDURE ITEMS
APPENDIX
Symbols and Classification
