3–7–2 OC Modification (continued)
h. DMP2 ASSY (Slot # 24)
Set the Dip SW (SW 06A2) as follows.
DC # 1 OFF OFF ON OFF
1234
Note
If two DC III’s are installed, set the Dip SW(Slot #23) for the second(DC # 2) as follows;
DC # 2 OFF OFF ON ON
1234
i. ZJBB ASSY (Back Board)
Set J201 jumpers to OPEN.
3. Board Installation
Install boards. See Illustration 3–24.
