3.5 Technical Details
Requirement Spec
SAE Compliant
Level II per J1772
Vehicle Interface
SAE J1772 EV connector
Cable Length
22 feet
AC Charging Power Output
**
7.2kW (240VAC @ 30A)
Voltage and Current Rating
208-240VAC @ 30A
AC Power Input
208-240VAC requiring only Line 1, Line 2, and Earth ground
Short Circuit Rating
5kA @ 240VAC
Recommended Service Panel
Breaker
Pole, Wall, Single Pedestal: 2-pole 40A breaker on dedicated
circuit
Double Pedestal: (Qty. 2) 2-pole 40A breaker on dedicated
circuit
Ground Fault Protection
Internal 20mA CCID w/ auto re-closure, does not require a
GFCI in service panel
Communication Option
CAT5 Ethernet, WiFi or Cellular (CDMA)
Metering
Accuracy
2% accurate on voltage and current
RFID Reader
HID MultiClass SE (model RP15EKNR)
Display Screen
Vacuum Fluorescent Display
Standby Power
5W typ.
Outdoor Rated
NEMA 3R
Safety Compliance (ETL Listing)
UL 2231, UL 2251, UL 2594, cUL 2231, cUL 2594, NEC 625, SAE
J1772
Surge Protection
6kV @ 3,000A
EMI Compliance
FCC Part 15 Class B
Operating Temperature
-30°C to +50°C ambient
Operating Humidity
Up to 95% non-condensing
Approximate Shipping Weights
Single Pedestal: 140 lbs
Double Pedestal: 175 lbs
Pole: 75 lbs
Wall: 75 lbs
Dimensions
Single Pedestal: 51.1"H x 14.9"W x 13.8"D
Double Pedestal: 51.1"H x 14.9"W x 13.8"D
Pole: 31.52"H x 11.82"W x 11.16"D
Wall: 31.52"H x 11.82"W x 11.16"D
Table – 3.2
**The maximum power consumption is determined by EVSE. The actual power consumption
is determined by EV.
