GE Fuji Electric FVR-C9S-2UX Series - Function Explanation

24
FVR-C9S-2UX
Function Code Tables
Function
Code
Function Date Code Range Unit
Min.
Set.
Factory
Setting
Change
During
Operation
F00 Data protection
0: Data change possible
1: Data change not possible
—— 0 No
F01
Frequency
Command
0: Keypad panel (UP/DOWN keys)
1: Analog input (VR, DC0 - 10V or DC4 - 20mA)
—— 1 No
F02
Operation
Command
0: Keypad panel operation (RUN/STOP keys)
1: External signal operation (FWD/REV terminals)
—— 0 No
F03
Maximum
Frequency
50 - 120 Hz Hz 1 60 Hz No
F04 Base Frequency 50 - 120 Hz Hz 1 60 Hz No
F05 Acceleration TIme 0.0 - 60s (0.0 setting = 0.01s) s 0.1 6.0s Yes
F06 Deceleration Time 0.0 - 60s (0.0 setting = 0.01s) s 0.1 6.0s Yes
F07 Torque Boost 0 - 31 (code) — — 13 Yes
F08
Electronic Thermal
Overload Relay
Operation
0: Inactive
1: Active (standard 4-pole motor)
2: Active (forced-air cooled motor)
—— 0 No
F09
Electronic Thermal
Overload Relay
Level
30 - 105% of rated current of drive % 1 100% No
F10
Restart after
Momentary Power
Failure
0: Inactive
1: Active (Restart drive in 0.5s after power failure)
—— 0 No
F11
Gain for Frequency
Setting Signal
0: For 0 - 10 V
1: For 0 - 5 V
—— 0 No
F12
DC Brake (Level
Setting)
0 - 100% — 1 50% Yes
F13 DC Brake (Time) 0.0 (inactive) 0.1 - 30s s 0.1 0.1s Yes
F14 Starting Frequency 1 - 6 Hz Hz 1 1 Hz No
C92-01
13. Function Explanation
