Features of Your Range
Stainless Steel Range
9
Design
information
(Not all features
are on all models.
Appearance may vary.)
Feature Index Page
1 12″ (small) Oven Crumb Catch Tray –
2 Oven Lights 27
3 Thermostat Bulb –
4 12″ (small) Oven Control Knob 17, 18, 22, 26
5 Cooktop Burner Control Knobs 10, 26
6 12″ (small) Oven Controls 17, 18, 22, 26
7 Burner Assemblies 10, 28
8 Model and Serial Numbers (in rear of burner
box below grates—can be seen when grates are removed) 3, 36
9 Back Panel and Shelf 30
10 Grille 13–15, 30
11 Drain Tubes 29
12 Griddle Flue Cover (Vent) 15
13 Griddle 15, 16, 29
14 Grille Control Knob 13, 26
15 27″ (large) Oven Controls 17, 21, 22, 25, 26
16 Griddle Control Knob 16, 26
17 Oven Light Switch –
18 27″ (large) Oven Control Knob 17, 21, 22, 25, 26
19 Drip Trays 13, 29
20 Broil Element 26
21 Convection Fan 20
22 Bake Element 26
23 Oven Shelf Slide Assemblies 24
24 Oven Door Gasket 8
25 Oven Door 22
