Specs:
120 Volt AC Components
• Circulation Pump: 120 VAC, .8 amp – 3.8 LRA, 8GPM @ 5PSI
• Drain Pump: 120 VAC, 27 ohms, .65 amp
• Heater: 120 VAC, 18 ohms wet – 23.4 ohms dry, 6.7 amp wet - 5.125
Watts, 800 wet / 650 dry +/- 5%
• Tub TCO: 120 VAC, 210f +/- 10 Manual Reset
• Main Control: 120 VAC / 5 & 13.5 VDC
DC Volt Components
• UI Control: 13.5 VDC input, 13.5 volts DC output (some models)
• Door Switch: 13.5 VDC
• Water Valve: 13.5 VDC, 32 ohms, .83 GPM
• Detergent Cup: 13.5 VDC , 32 ohms
• Turbidity Sensor: .24-3.8 VDC, 10K ohms
• Flood Switch: 13.5 VDC, .42 amp
• Thermistor (in flood switch): Resistance Temperature
20K 50
11K 75
5.8K 100
3.4K 125
2.1K 150
1.3K 175
