Separating the Door
1. Remove door
2. Place door assembly on protected surface Outer panel down
3. Remove Vent Cap on top Control Doors
4. Push vent conduit into door area
5. Remove 2 – ¼ hex head screws approximately 3 inches from
bottom of outer panel Photo
6. Slide inner panel up to release the tabs holding the 2 panels
together. The components and wiring will remain with the inner
door panel
Tab (7 each side)
Section of door
