Copyright General Electric 2011
9/23/2012
Flood Switch Removal
To remove Flood switch:
Remove Fine Filter
Remove Vent Caps
Remove Coarse Filter
Remove Filter Adapter
Remove 2 ¼ inch hex head screws
Remove Floor Plate and Flood Switch
Disconnect wire harness
Filter Adapter
Floor Plate
¼” hex screws
Flood Switch
