Normal Operating Characteristics
¾ Liner protection mode will turn on either the fresh food or freezer fan if the doors
or drawer are open for more than 3 minutes* respectively.
¾ The condenser fan may run without the compressor operating*
¾ Dispenser will not operate with either fresh food door open*
¾ Fan(s) running without the compressor operating is normal.
¾ The variable speed compressor uses an inverter like previous variable speed.
¾ The compressor will start at high speed for 1 minute, then may change to a lower
speed based on fresh food and freezer temperature. This may be perceived as a
noise issue.
¾ There is a 20* second compressor delay on power up, but fans will start
immediately if cooling is required.
¾ Compressor maximum run time is limited to 6* hours and the minimum
compressor off time is 3* minutes.
* Values are approximate and preliminary
