Maintenance
Intervention on the FK3- 4 operating device
GE Information L51- 303EN/05
2/10
11- 2016
Positions of optical signalization
“A” position
Circuit- breaker
Open
Closing spring
Loaded
“B” position
Circuit- breaker
Closed
Closing spring
Released
“C” position
Circuit- breaker
Closed
Closing spring
Loaded
“D” position
Circuit- breaker
Open
Closing spring
Released
