Installation Instructions
13
REVERSING THE DOOR
ABOUT REVERSING THE DOOR
IMPORTANT NOTES:
• Read the instructions all the way through before
starting.
• Handle parts carefully to avoid scratching paint.
• Set screws down by their related parts to avoid
using them in the wrong places.
• Provide a non-scratch work surface for the door.
• Normal completion time to reverse the door
swing is 30–60 minutes.
IMPORTANT:
Once you begin, do not move the cabinet until door
swing reversal is completed. These instructions are
for changing the hinges from the right side to the left
side - if you ever want to switch them back to the
right side, follow these same instructions and reverse
all references to the left and right.
Tools needed:
Standard #2 Phillips screwdriver
Tape-tipped putty knife
Small flat blade screwdriver
Before you start
Unplug the dryer from its
electrical outlet
Choose the REVERSING THE DOOR instructions
A
or
B
for your model.
A
REVERSING THE DOOR - SOLID DOOR
MODELS
1
Open the door approximately 130 degrees. With a
putty knife, remove the 4 plastic caps located along
the left side of the front panel and set them aside.
2
Remove the bottom screw from each hinge (right
side) and partially insert them into each top hinge
hole on the left side.
NOTE: All 4 front panel hinge screws will now be in
the top hinge holes - 2 on the left and 2 on the right.
3
Loosen each top hinge screw on right side. Remove
the door and place it on a protective flat surface to
avoid any damage.
4
Remove both the blind plate and the strike plate and
install them in opposite positions.
A
REVERSING THE DOOR - SOLID DOOR
MODELS (cont.)
Plastic Cap (4)
Left side of
front panel
Blind
plate
Strike
plate
Loosen each top
hinge screw on
right side
To Next Page
