GE GTD65EBPLDG Installation Instructions

Installation Instructions
15
B
REVERSING THE DOOR - GLASS PANEL
DOOR MODELS
1
Open the door approximately 130 degrees. With a
putty knife, remove the 4 plastic caps located along
the left side of the front panel and set them aside.
2
Remove the bottom screw from each hinge (right
side) and partially insert them into each top hinge
hole on the left side.
NOTE: All 4 front panel hinge screws will now be in
the top hinge holes - 2 on the left and 2 on the right.
3
Loosen each top hinge screw on right side. Remove
the door and place it on a protective flat surface to
avoid any damage.
B
REVERSING THE DOOR - GLASS PANEL
DOOR MODELS (cont.)
4
Remove both the blind plate and the strike plate and
install them in the opposite positions.
5
Remove the 4 door hinge screws, 6 inside screws and
2 pocket screws. Lift the inner door upwards using a
flat blade screwdriver.
Plastic Cap (4)
Left side of
front panel
Blind
plate
Strike
plate
Inner door
Outer door
Inside
screws
Inside
screws
Pocket screws
Inside
screw
Door
hinge
screws
Loosen each top
hinge screw on
right side

GE GTD65EBPLDG Specifications

General

Color	white, diamond gray
Dryer Capactity	7.4 cubic feet
Number of Cycles	4
Cycle Selections	anti-bacterial, towels and sheets, antibacterial, bulky items, damp dry, extended tumble, jeans, mixed load, my cycle, quick fluff, sanitize, towels/ sheets
Options	extended tumble
Stackable	no
Venting	true, vented
Temperature Settings	5
Temperature Selections	high, medium, low, extra low, no heat
Temperature Control	yes
Delay Start	yes
Child Lock	no
Cycle Signal	yes
Interior Light	yes
Drying Rack	no
Moisture Sensor Option	yes
Steam	no
Smart Home	no
Voltage	240 volts
Current	24 amperes

Weight and Dimensions

Depth	30 1/2 inches
Height	46 inches
Width	27 inches
Net Weight	107 pounds
