Specication for 18 Cu Ft Mechanical Timer
Refrigerator
DISCONNECT POWER CORD BEFORE SERVICING
IMPORTANT - RECONNECT ALL GROUNDING
DEVICES
All parts of this appliance capable of conducting
electrical current are grounded. If grounding wires,
screws, straps, clips, nuts or washers used to
complete a path to ground are removed for service,
they must be returned to their original position and
properly fastened.
IMPORTANT SAFETY NOTICE
This information is intended for use by individuals
possessing adequate backgrounds of electrical,
electronic and mechanical experience. Any attempt
to repair a major appliance may result in personal
injury and property damage. The manufacturer or
seller cannot be responsible for the interpretation of
this information, nor can it assume any.
ELECTRICAL SPECIFICATIONS
Temperature Control (Colder) 23.9-11.1°F /
(-4.5) - (-11.6)°C
Defrost Control 15 hrs/ 33 min
Defrost Thermostat 64-23°F / 17.8 -
(-5.0)°C
Electrical Rating: 110V to
127V AC 60Hz 100V AC 50 Hz
6.5 Amp
Maximum Current Leakage 0.75 mA
Maximum Ground Path
Resistance
0.14 Ohms
NO LOAD PERFORMANCE
Control Position,
Colder Temperature
of
70°F /
21°C
90°F /
32°C
Fresh Food, °F / °C 34-40
/1.1-4.4
35-39 /
1.7-3.9
Frozen Food, °F / °C -3 / -19.4 -3 / -19.4
Running Time % 20-30 41-53
REFRIGERATION SYSTEM
Refrigerant Charge
(R134a)
Refer to Rating Plate
Compressor Capacity
(@ 10°F Evap and
105°F Cond)
600 BTU/hr / 175.8W
Minimum Vacuum @ 2
minutes
19 inches / 48 cm
Minimum Equalized Pressure
@70°F / 21°C 26 PSIG / 179 kPa
@90°F / 32°C 35 PSIG / 241 kPa
INSTALLATION
Clearance must be provided for air circulation
TOP 1 inch / 25 mm
SIDES 3/4 inch / 19 mm
REAR 2 inch / 50 mm
REPLACEMENT PARTS
Temperature Control WR09X21005
Relay WR08X22874
Defrost Control WR09X10049
Defrost Thermostat WR50X22304
Defrost Heater WR09X21107
Condenser Fan Motor WR17X21162
Evaporator Fan Motor WR60X10346
Drier WR86X0096
Harness Jumper Fuse WR55X21096
Pub. No. 31-51904
