GE GUD24GSSMWW User Manual

– 8 –
6SHFL¿FDWLRQV
:LQGLQJV&RLOV5HVLVWDQFH9DOXHV
Main Drum Motor
Start

Run

Blower Motor - 
Heater Coils 27"
Inner 
Outer 
Heater Coils 24"
Inner 
Outer 
Timer Motor - 
,QOHWO u t l e t
Biased Thermostats
- N
Thermostat
Temperature °F Temperature °C
Open Close Open Close
Drum Outlet
130 +/- 5
120 +/- 6 55 +/- 3 49 +/- 3
Control Outlet 210 +/- 5 180 +/- 6 99 +/- 3 82 +/- 3
&RQWURO,QOHW/RQJ9HQW
Only)
205 +/- 5 175 +/- 6 96 +/- 3 79 +/- 3
Safety 235 +/- 5 205 +/- 6 113 +/- 3 96 +/- 3
6DIHW\/RQJ9HQW2QO\ 225 +/- 5 195 +/- 6 107 +/- 3 91 +/- 3
+LJK/LPLW 315 +/- 8 250 +/- 15 157 +/- 6 121 +/- 9
Terminal Wire Color
C Pink
U Brown/Yellow
Y Yellow
X Yellow
A Orange
T Tan
S Blue
B Red
F Not Used
Electric Dryer

GE GUD24GSSMWW Specifications
