General Electric parts catalog
Customer Service Troubleshooting Tips
Operating Instructions
Safety Instructions
Installation Instructions
Customer Service Troubleshooting Tips
Installation Instructions
Safety Instructions
Operating Instructions
Customer Service Troubleshooting Tips
Installation Instructions
Safety Instructions
Operating Instructions
REF. NO. PART NO. PART DESCRIPTION GXRV10ABL01
0001 WS15X10003 FAUCET WHITE TIP & LEVER -
WS15X10011 FAUCET BLACK TIP & LEVER 1
0004 WS02X10007 SCREW #6-32 X 1 -3/8² 2
0006 WS08X10003 GASKET FAUCET 1
0007 WS02X10008 NUT 2
0008 WS03X10003 ADAPTER TUBING 1
0009 WS22X10005 NUT 1/4² TUBE 8
0010 WS22X10006 INSERT 1/4² TUBE 7
0012 WS22X10007 INSERT 3/8² TUBE 7
0013 WS22X10008 NUT 3/8² TUBE 7
0014 FX12PA CARTRIDGE–CARBON/SED 2
0017 WS03X10004 WASHER FLOW 1
0018 WS01X10001 MAGNET 1
0019 WS03X10005 SPRING 1
0021 WS10X10005 VALVE BOTTOM 1
0022 WS22X10009 DIAPHRAGM 2
0023 WS22X10010 PLUNGER 1
0024 WS22X10012 ELBOW 1/8² NPT X 1/4² 1
WS22X10011 ELBOW 1/8² NPT X 1/4² & NUT 3
0025 WS22X10013 CONNECTOR W/NUT 1/8 NPT 1
WS22X10014 CONNECTOR 1/8 NPT X 1/4 1
0026 WS10X10006 VALVE TOP 1
0027 WS10X10007 VALVE CENTER 1
0028 WS02X10010 SCREW # 10-14 X 1-3/4² 4
0030 WS32X10006 TANK–2.1 GAL. 1
0032 WS02X10018 CLIP 2
0033 WS02X10017 SCREW 4
0034 WS10X10012 CHECK BALL ASM 1
0035 WS20X10004 CARTRIDGE–R.O. 1
0036 WS22X10024 TEE 3/8² TUBING 1
0037 WS02X10004 NUT 3/8² 2
0041 WS15X10008 WATER SUPPLY VALVE* 1
0043 WS03X10015 SCREEN CONE 1
0044 WS03X10016 CONTROL FLOW 1
0045 FX12M MEMBRANE CARTRIDGE 1
0047 WS07X10005 TUBING 1/4² X 10 FT 1
0048 WS07X10006 TUBING 1/4² X 20 FT 1
0049 WS07X10007 TUBING 3/8² X 20 FT 1
0050 WS07X10008 TUBING 3/8² X 20 FT 1
0053 WS03X10026 U-PIN 1
0057 WS03X10028 O-RING 1-19/32² ID 2² OD 1
0058 WS31X10009 COVER INLET 1
0059 WS02X10001 SCREW #10-14 X 3/4² 8
0060 WS28X10006 BRACKET 1
0061 WS19X10001 HEAD 2
0062 WS22X10002 ELBOW 3/8² NPT X 3/8² 2
0063 WS03X10001 O-RING 3-3/8² X 3-5/8² 2
0064 WS30X10001 SUMP 2
0065 WS22X10025 TEE 3/8 NPT X 3/8 TUBE 1
0066 WS22X10026 ELBOW 3/8 NPT X 1/4 TUBE 2
0067 WS03X10030 SPRING 1
0068 LOCK WASHER 1
0069 FLOW RESTRICTER
0070 DRAIN LINE ADAPTER
0200 WX5X140 WRENCH SUMP -
0999 49-50005 PM MANUAL USE & CARE/ 1
INSTALLATION
PERFORMANCE DATA SHEET
VIDEO
WATER TEST KIT
*NOTE: Codes in the State of
Massachusetts require installation
by a licensed plumber and do not
permit the use of the saddle valve.
For installation, use plumbing code
248-CMR of the Commonwealth of
Massachusetts.
