Installation Instructions
• Using the chart below determine if the width of your passageway can accommodate the depth of the refrigerator. Ensure you have clearance
to prevent damage to the refrigerator before safely moving it to the final location.
• If passageways are large enough to accommodate the refrigerator without removing the handles skip to Step 6. Leave tape, film and all
packaging on doors until the refrigerator is in the final location.
• NOTE: Use a padded hand truck or moving straps to move this refrigerator. Place the refrigerator on the hand truck with a side against
the truck. We strongly recommend that two people move and complete this installation.
Moving THE REFRIGERATOR
DIMENSIONS
All measurements are given with leveling leg fully retracted.
SD CD
Overall Height to Top of Hinge Cover
69
7
ø8
”69
7
ø8
”
Height to Top of Cabinet
69” 69”
Case Depth without Doors 29
3
ø8
”24
3
ø8
Overall Exterior Case Width
35
3
ø4”35
3
ø4”
Overall Exterior Depth Doors/Drawers with Handles 36¼” 31¼”
Standard Depth (SD) Models OnlyCounter Depth (CD) Models Only
If your model number starts with PFE (SD)
If your model number starts with CFE (SD)
36.25” 35.25” 29.375”
33.75”
30.25”
If your model number starts with GFE, DFE, GNE (SD)
If your model number starts with CYE, PYE, PWE (CD)
31.25”
30.25”
28.75”29.75”
24.375”
25.25”
Case Depth w/o
Doors 29
3
ø8
” SD
24
3
ø8
” CD
Height from
floor to hinge
cover top 69
7
ø8”
Additional Dimensions
23
1
ø4” SD
18
1
ø4” CD
35
3
ø4”
69”
31
1
ø4”
69
7
ø8
”
35
3
ø4”
69”
36
1
ø4”
69
7
ø8
”
(PWE)
