GE GYE22KSHSS User Manual

Installation Instructions
INSTALLING THE REFRIGERATOR (cont.)
26
REMOVE THE FREEZER DOOR
Pull the freezer door open to full extension.
Remove 3 attachment screws, located at the bottom
on each side of the freezer door using 3/8” hex socket
driver.
CAUTION
Lifting Hazard
Freezer door is heavy Use both hands to secure the
door before lifting.
Lift the freezer door to disengage it from the slide
mechanism
The door can safely rest on the bottom. Do not rest the
door on any other surfaces to avoid scratches.
Push the slide mechanism back completely until it self
retracts.
A
B
C
6
REPLACING THE FREEZER DOOR
Pull the slide Mechanism to full extension using both
hands simultaneously.
Remove the basket resting on the slides.
CAUTION
Lifting Hazard
Freezer door is heavy Use both hands to secure the
door before lifting.
Lift the freezer door and place it on the slide mechanism
Replace the attachment screws and torque the screws
to 65 in-lb
For adjusting freezer door gaps, follow the instructions
on pg 27.
Replace the basket
A
B
C
D
7
E
F
Align and insert
tab on Freezer
Door Bracket
with slot on
Freezer Slide
Bracket.

GE GYE22KSHSS Specifications

General

Type	freestanding
Style	french door
Color	stainless steel
Refrigerator Capacity	14.9 cubic feet
Freezer Capacity	7 cubic feet
Humidity Controlled Crispers	yes
Defrost System	manual
Number of Refrigerator Door Bins	yes
Temperature Control	digital
Interior Light	led
Ice Maker	yes
Water Filter	yes
Door Alarm	yes
Smart Home	no
Annual Energy Consumption	664 kilowatt hours
Current	15 amperes

Weight and Dimensions

Depth	31.25 inches
Height	69.875 inches
Width	35.75 inches
Net Weight	333 pounds
