24 49-3000217 Rev 5
Installation Instructions
REVERSING THE DOOR SWING (Optional)
REMOVE, REVERSE AND
REPLACE THE DOOR STRIKER
• Remove the 2 screws from the striker. Rotate the
striker 180° and reinstall the striker with its screws.
3
REMOVE THE DOOR STRIKER
ASSEMBLY AND REPLACE ON
THE OPPOSITE SIDE
4
• Remove the 2 screws from the striker assembly and
remove the assembly by pulling it toward the center,
pushing it up and pulling it out.
• Rotate the striker assembly and replace it on the
opposite side with its screws.
